Complete Booster Pump System, Turn-Key Package
Full-scope booster pump systems: vertical multistage pumps plus VFD duplex control panel plus hydropneumatic bladder tank plus mechanical installation and commissioning. One quote, one delivery, one accountable supplier. Documented for permit and warranty purposes.
WRAS · ISO 9001 · TÜV · CE · ASME · PED|Nationwide PH delivery|Quote in 3 to 5 business days|1 business day response
Request a Quotation
Send us your requirements and we'll prepare a detailed quotation with pricing and scope of supply.
Related Products
Vertical Multistage Centrifugal Pump
CDL/CDLF series stainless steel pumps for building water supply, boiler feed, and industrial pressure boosting. 0.37kW to 200kW.
VFD Duplex Pump Control Panel
Intelligent pump control with Variable Frequency Drive, PLC automation, and 7" HMI touchscreen. Constant pressure, energy savings of 20-35%.
Hydropneumatic Pressure Tank
ASME-rated bladder-type pressure tanks for commercial water systems. Stabilizes pressure, prevents pump short-cycling, extends motor life.
Overview
Our complete pump system package bundles every major component for a commercial water distribution setup — matched, specified, and documented as one cohesive product package. We size and select based on your building's requirements: floor count, fixture count, peak demand, and pipe losses. The package includes duplex vertical multistage pumps (for redundancy), a VFD control panel with PLC + HMI, a hydropneumatic pressure tank, and the supporting piping accessories, valves, fittings, and instruments. Each component carries its own manufacturer warranty and comes with complete documentation (test certificates, performance curves, electrical schematics).
Key Features
Technical Specifications
| System Type | Duplex / Triplex constant-pressure booster |
| Pump Type | Vertical multistage centrifugal (CDL series) |
| Control Panel | VFD + PLC + HMI (7" touchscreen) |
| Pressure Tank | Bladder-type hydropneumatic (ASME) |
| Piping | SS304 / Galvanized / HDPE accessories |
| Valves | Gate, check, ball, pressure relief |
| Instruments | Pressure gauges, flow meters, sensors |
| Documentation | Test certificates, performance curves, schematics |
Applications
System Configurations & Lead Times
| System class | Pumps | VFD panel | Bladder | Typical building | Lead time |
|---|---|---|---|---|---|
| Small commercial | 2x 2.2 kW | Duplex 2.2 kW | 300 L | 4-6 storeys, boutique hotel, small clinic | 30-45 days |
| Mid-size commercial | 2x 5.5 kW | Duplex 5.5 kW | 500 L | 6-10 storeys, medium hotel, medium laundry | 30-45 days |
| Large commercial | 2x 11 kW | Duplex 11 kW | 1,000 L | 10-15 storeys, large laundry, mid-rise hospital | 35-50 days |
| High-rise / industrial | 2x 22 kW or 3x 15 kW | Duplex / Triplex | 2,000 L | 15-25 storeys, high-throughput industrial | 45-60 days |
| Custom engineered | Sized to site | Engineered | Sized | Utility, district cooling, unique operations | 60-90 days |
Scope options: supply only (equipment delivered, install by others), supply + mechanical install (connect to your existing tie-in points), or turn-key (equipment + install + electrical + commissioning + operator training).
Who Typically Buys This
What Determines Your Quote
Every quote is engineered to your operating requirements. Pricing depends on:
- Configuration: capacity, flow rate, head pressure, motor size, voltage/phase, materials of construction
- Certification tier: WRAS-cert vs commercial-grade, ASME stamping, IP rating for panels
- Delivery region: nationwide (Metro Manila, Luzon, Visayas, Mindanao); freight varies by destination
- Installation scope: supply-only, supply + mechanical install, or full turn-key with commissioning
- Payment structure: milestone terms tailored to project timeline (typically 40/30/20/10 for engineered scopes; 70/30 for equipment supply)
- Tax status: 12% VAT applies to VAT-registered buyers; Zero-VAT available for eligible PEZA / SBMA locators and exporters
Formal written quote within 3 to 5 business days of complete spec confirmation. Response within 1 business day to every inquiry.
Frequently Asked Questions
What's included in a turn-key system?
Everything from equipment to a running system: vertical multistage pumps, VFD duplex control panel, hydropneumatic bladder tank, mechanical installation, electrical connection, commissioning, and operator training. You get one quote, one delivery schedule, and one accountable team, with no finger-pointing between separate suppliers.
What documentation comes with the system?
Every system ships with material test certificates for the pumps and panel, operation manuals, electrical schematics, pump performance curves, VFD parameter list, commissioning report, and warranty certificates. This full package covers permits, compliance audits, and future maintenance reference.
Can I buy supply-only and install with my own contractor?
Yes. All three scope options are available: supply only, supply plus mechanical install, or full turn-key. We quote them separately so you can compare the numbers and choose what fits your project and your contractor arrangements.
How fast can a system be running?
Small and mid-size commercial systems run 30 to 45 days from down payment to commissioning. Large commercial systems run 35 to 50 days, high-rise and industrial 45 to 60 days, and custom-engineered scopes 60 to 90 days. Installation itself typically takes 3 to 7 days on-site once equipment arrives.
Which regions do you deliver and install in?
Complete systems are delivered across Metro Manila, all Luzon provinces, the Visayas, and Mindanao, with regular projects completed inside SBMA, Clark, and PEZA industrial estates where we handle the gate pass and work permit coordination. For supply-plus-install and turn-key scopes, our installation team mobilizes to provincial and industrial estate sites as well, and the mobilization cost is itemized in the quotation so you see exactly what the distance adds to the total. Pumps, control panel, and bladder tank are crated separately, checked against the full packing list, and scheduled to arrive together so your pump room is not half-built waiting on one crate. Send your site address and scope preference (supply-only, supply plus install, or turn-key) with your inquiry: we respond within 1 business day and release the full quotation within 3 to 5 business days.
Can you build a system outside the standard configurations?
Yes. The standard classes cover most commercial buildings, but custom-engineered systems are sized to site for utility-scale distribution, district cooling, and operations with unusual demand profiles. Customization covers pump count and sizing (duplex or triplex with lead-lag-standby), panel configuration, bladder tank capacity, and the piping accessories, valves, and instruments that tie it together, all matched as one package rather than mixed from separate suppliers. Custom scopes run 60 to 90 days because sizing calculations and drawings are prepared and approved before anything is fabricated, and the confirmed schedule is stated in the written quotation. To get started, send your building profile (floor count, fixture or machine count, peak demand if known, and any existing equipment you are keeping) and we return the sizing math with a complete specced quotation within 3 to 5 business days.
Related Products in Pumping & Pressure Systems
Ready to Spec This In?
Send us your requirements (capacity, location, timeline, install scope) and we'll return a fully specced quotation with drawings, material certificates, and lead time within 3 to 5 business days.
Request a Quotesales@johob.com · +63 997 078 9953 (Viber)
Common inquiries we can answer today: sizing math, alternative product recommendations, delivery estimates, milestone payment structures, PhilGEPS or PEZA compliance paperwork.
